Universal Hitch - Model A


Horizontal Assembly
Universal Hitch Model A Horizontal Assembly

Vertical Assembly
Universal Hitch Model A Vertical Assembly

Item #

Description:

Weight Estimate

Price

UNIVHITCHA

Universal Hitch  Model  A

275 lbs

$ 1,485.00

Please Note - Our standard color is black. Custom colors are available upon request

Description:

The White Mule Universal Hitch is a towing hitch that is designed to attach to the frame of almost any tractor or box truck. The design allows for multiple assemblies in various positions making it one of the most versatile towing hitches on the market.


Universal Hitch Video by truckmovers.com   Universal Hitch Installation Video by truckmovers.com


Universal Hitch - Model A - Complete With:

Hardware:
  • (1) 5/8" x 4" Hex Bolt
  • (1) 5/8" Hex Nut
  • (1) 5/8" L.W.
  • (1) 3/4" x 4-1/2" Hex Bolt
  • (6) 3/4" x 6-1/2" Hex Bolt
  • (6) 3/4" x 8" Hex Bolt
  • (2) 3/4" x 9" Hex Bolt
  • (17) 3/4" Hex Nut
  • (17) 3/4" L.W.
  • (1) 2" Ball Hitch
  • (1) 1" Hex Nut
  • (1) 1" Medium L.W.
  • (5) 5/8" Hitch Pin
(1) Main Cross Member

(2) Clamp Plate
  • (2) 1/2" x 4" x 6" Three Hole Support Plate
(1) Horizontal Adjustable Support

(1) Vertical Adjustable Reciever

(1) 24" Ball Hitch Assembly w/ 2" Ball

(1) Stabilizer Bar
  • (1) 1/2" x 2" x 5-1/2" Two Hole Support Plate
(2) Stabilizer Clamp Bar
  • (2) 1/2" x 2" x 6" Three Hole Support Plate
(1) Adjustable Support Tube Set


Universal Hitch - Model A - Optional Accessories:

(2) Long Clamp Bar
  • (2) Double Frame Clip
  • (2) 3/4" x 13" Hex Bolt
(2) Short Clamp Bar

Please Note - Tow Bar Not Included.

Please refer to the link below for U.S. Department Of Transportation Regulations
FMCSA link
https://www.fmcsa.dot.gov/regulations/title49/section/393.71

Warning
